DISPLACEMENT
MAX. POWER
MAX. SPEED
ENGINE/ BRAKE
LOADING CAPACITY | CBU，34 UNITS/40HQ | |
Disassemble the handlebar, front wheel, front wheel cover, speedometer, | ||
BASIC SPECS. | FOB RMB PRICE | |
MODEL | GT400i F | |
CERTIFICATE | EURO 5+ | |
MAX. SPEED(km/h) | 140 | |
ENDURANCE MILEAGE(km) | 480 | |
VEHICLE SPECS. | LENGTH(mm) | 2170 |
WIDTH(mm) | 810 | |
HEIGHT(mm) | 1325 | |
SEAT HEIGHT(mm) | 780 | |
WHEEL BASE(mm) | 1550 | |
MIN. GROUND CLEARANCE(mm) | 125 | |
FRAME TYPE | BRAIDED BRIDGE-TYPE FRAME | |
FRONT SUSPENSION SYSTEM | UPRIGHT STRAIGHT CYLINDER SHOCK ABSORBER | |
REAR SUSPENSION SYSTEM | SPRING DUAL GASBAG REAR SHOCK ABSORBER | |
FUEL CAPACITY(L) | 16 | |
NET WEIGHT(kg) | 195 | |
GROSS WEIGHT(kg) | 205 | |
FORWARD ANGLES(°) | 28 | |
ENGINE SPECS. | ENGINE TYPE | 1P80MP |
DISPLACEMENT(cc) | 400 | |
PRECISE DISPLACEMENTcc) | 369.3 | |
INTAKE TYPE | NATURALLY ASPIRATED | |
CYLINDER NUMBERS | SINGLE CYLINDER | |
GAS DISTRIBUTION STRCTURE(CAM TYPE) | SOHC | |
GAS DISTRIBUTION STRCTURE(VALVE NUMBERS) | 4 VALVES PER CYLINDER | |
BORE×STROKE(mm) | 80×73.47 | |
STROKES | 4 STROKES | |
COMPRESSION RATIO | 10.1:1 | |
COOLING TYPE | WATER COOLING | |
MAX. POWER(kw) | 22.5 | |
MAX. POWER RATATIONAL SPEED(rpm) | 7000 | |
MAX. TORQUE(N·m) | 34.5 | |
MAX. TORQUE SPEED(rpm) | 5500 | |
ENERGY TYPE | GASOLINE | |
OIL # | #92 | |
EFI/ CARBURETOR | EFI | |
OFFICIAL AVERAGE FUEL CONSUPTION(L/100km) | 3.3 | |
POWER TRANSMISSION | GEAR SHIFT | CVT Stepless Speed Change Automatic Transmission |
CVT | Dry Centrifugal Type Clutch | |
DRIVE TYPE | Belt Drive | |
WHEEL & BRAKING | BRAND/ MODEL | CST |
FR. TIRE | 120/80-14 | |
RR. TIRE | 150/70-14 | |
TIRE TYPE | VACUUM TIRE | |
RIM TYPE | ALUMINUM CASTING | |
FR. BRAKE | DISC BRAKE | |
RR. BRAKE | DISC BRAKE | |
ACTIVE/ PASSIVE SECURITY CONFIGURATION | ABS ANTI-LOCK BRAKING SYSTEM | STANDARD CONFIGURATION |
TIRE PRESSURE MONITORING | STANDARD CONFIGURATION | |
TCS | STANDARD CONFIGURATION | |
ASSISTANT/ CONTROL CONFIGURATION | MODE SELECTION | WITHOUT |
THROTTLE | DOUBLE THROTTLE | |
QUICK SHIFT SYSTEM(Y/N) | WITHOUT | |
RAPID GEAR SHIFT SYSTEM | WITHOUT | |
ESA | WITHOUT | |
CRUISE CONTROL | WITHOUT | |
HYDRAULIC CLUTCH | WITHOUT | |
ENGINE START & STOP | WITHOUT | |
PULSE IGNITION SYSTEM | WITHOUT | |
MULTIMEDIA & COMFORT CONFIGURATION | SPEEDOMETER | 7-inch TFT SCREEN DISPLAY |
MOBILE PHONE CONNECTION | STANDARD CONFIGURATION | |
NAVIGATION SCREEN PROJECTION | STANDARD CONFIGURATION | |
GEAR DISPALY | WITHOUT | |
USB CHARGING PORT | STANDARD CONFIGURATION | |
KEYLESS START | STANDARD CONFIGURATION | |
ELECTRIC HEATING HANDLE | WITHOUT | |
ELECTRIC HEATING SEAT | WITHOUT | |
WINDSCREEN | STANDARD CONFIGURATION | |
LIGHT | HEADLIGHT | LED |
TAIL LIGHT | LED | |
TURN SIGNAL LIGHT | FR.: Hologen RR.: LED | |
ASSISTANT LIGHT | WITHOUT | |
WARNING LIGHT | STANDARD CONFIGURATION | |
AUTOMATIC HEADLIGHT | WITHOUT | |
OTHER CONFIGURATION | CONFIGURATION | STANDARD CONFIGURATION: SIDE STAND WITH ENGINE SHUTDOWN |
