DISPLACEMENT
MAX. POWER
MAX. SPEED
ENGINE/ BRAKE
| LOADING CAPACITY | CBU, 34 UNITS/ 40HQ | |
| Disassemble the handlebar, front wheel, front wheel cover, speedometer assy. 50 UNITS/40HQ | ||
| CKD, 63 UNITS/ 40HQ | ||
| BASIC SPECS. | FOB NINGBO PRICE US$ | |
| MODEL | GT400i S | |
| CERTIFICATE | E5+ | |
| MAX. SPEED(km/h) | 145 | |
| ENDURANCE MILEAGE(km) | 480 | |
| VEHICLE SPECS. | LENGTH(mm) | 2170 |
| WIDTH(mm) | 810 | |
| HEIGHT(mm) | 1375 | |
| SEAT HEIGHT(mm) | 780 | |
| WHEEL BASE(mm) | 1550 | |
| MIN. GROUND CLEARANCE(mm) | 125 | |
| FRAME TYPE | CRADLE FRAME | |
| FRONT SUSPENSION SYSTEM | UPRIGHT STRAIGHT CYLINDER SHOCK ABSORBER | |
| REAR SUSPENSION SYSTEM | SPRING DUAL REAR SHOCK ABSORBER | |
| FUEL CAPACITY(L) | 16 | |
| NET WEIGHT(kg) | 195 | |
| GROSS WEIGHT(kg) | 205 | |
| FORWARD ANGLES(°) | 28 | |
| ENGINE SPECS. | ENGINE TYPE | 1P80MP |
| DISPLACEMENT(cc) | 400 | |
| PRECISE DISPLACEMENTcc) | 369.3 | |
| INTAKE TYPE | BRAIDED BRIDGE-TYPE FRAME | |
| CYLINDER NUMBERS | SINGLE CYLINDER | |
| GAS DISTRIBUTION STRCTURE(CAM TYPE) | SOHC | |
| GAS DISTRIBUTION STRCTURE(VALVE NUMBERS) | 4 VALVES | |
| BORE×STROKE(mm) | 80×73.47 | |
| STROKES | 4 STROKES | |
| COMPRESSION RATIO | 10.1:1 | |
| COOLING TYPE | WATER COOLING | |
| MAX. POWER(kw) | 23.6 | |
| MAX. POWER RATATIONAL SPEED(rpm) | 7200 | |
| MAX. TORQUE(N·m) | 36.2 | |
| MAX. TORQUE SPEED(rpm) | 5250 | |
| ENERGY TYPE | GASOLINE | |
| OIL # | #92 | |
| EFI/ CARBURETOR | EFI | |
| OFFICIAL AVERAGE FUEL CONSUPTION(L/100km) | 3.3 | |
| POWER TRANSMISSION | GEAR SHIFT | CVT Stepless Speed Change Automatic Transmission |
| CVT | Dry Centrifugal Type Clutch | |
| DRIVE TYPE | Belt Drive | |
| WHEEL & BRAKING | BRAND/ MODEL | CST |
| FR. TIRE | 120/80-14 | |
| RR. TIRE | 150/70-14 | |
| TIRE TYPE | VACUUM TIRE | |
| RIM TYPE | ALUMINUM CASTING | |
| FR. BRAKE | DISC BRAKE | |
| RR. BRAKE | DISC BRAKE | |
| ACTIVE/ PASSIVE SECURITY CONFIGURATION | ABS ANTI-LOCK BRAKING SYSTEM | STANDARD CONFIGURATION |
| TIRE PRESSURE MONITORING | STANDARD CONFIGURATION | |
| TCS | STANDARD CONFIGURATION | |
| ASSISTANT/ CONTROL CONFIGURATION | MODE SELECTION | — 无 |
| THROTTLE | DOUBLE THROTTLE | |
| QUICK SHIFT SYSTEM(Y/N) | WITHOUT | |
| RAPID GEAR SHIFT SYSTEM | WITHOUT | |
| ESA | WITHOUT | |
| CRUISE CONTROL | WITHOUT | |
| HYDRAULIC CLUTCH | WITHOUT | |
| ENGINE START & STOP | WITHOUT | |
| PULSE IGNITION SYSTEM | WITHOUT | |
| MULTIMEDIA & COMFORT CONFIGURATION | SPEEDOMETER | 7-inch TFT COLOR DISPLAY SCREEN |
| MOBILE PHONE CONNECTION (BLUETOOTH/WIFI) | STANDARD CONFIGURATION | |
| NAVIGATION SCREEN PROJECTION | STANDARD CONFIGURATION | |
| GEAR DISPALY | WITHOUT | |
| USB CHARGING PORT | STANDARD CONFIGURATION | |
| KEYLESS START | STANDARD CONFIGURATION | |
| ELECTRIC HEATING HANDLE | WITHOUT | |
| ELECTRIC HEATING SEAT | WITHOUT | |
| WINDSCREEN | STANDARD CONFIGURATION | |
| WINDSCREEN(ADJUSTABLE OR NOT) | WITHOUT | |
| WINDSCREEN(ADJUSTABLE POSITIONS) | WITHOUT | |
| LIGHT | HEADLIGHT | LED |
| TAIL LIGHT | LED | |
| TURN SIGNAL LIGHT | LED | |
| ASSISTANT LIGHT | WITHOUT | |
| WARNING LIGHT | STANDARD CONFIGURATION | |
| AUTOMATIC HEADLIGHT | WITHOUT | |
| OTHER CONFIGURATION | CONFIGURATION | STANDARD CONFIGURATION: DRIVING RECORDER, SIDE STAND WITH ENGINE SHUTDOWN |
| Remark: Price based on FOB NINGBO and keeps valid in 10 days. Price should be re-checked before order due to the fluctuations in raw material costs and exchange rate. | ||
